Non-contact and non-wearing measurement reduces maintenance and servicing cost
Sensor replacement possible even with chemicals present, thus saving time and increasing availability
Universally applicable with acidic and alkaline processes
Flexible measurement system for different container sizes provides cost reductions
High accuracy measurements, even in liquids with density fluctuations
Faultless operation with very limited installation space in the tote
Switching output and analog output in a single sensor reduces time and money spent on wiring
Simple and time-saving configuration with Connect+
| Measurement principle | Ultrasonic sensor |
| Detection principle | Non contact |
| Medium | Fluids |
| Measurement | Switch, Continuous |
| Process temperature | –25 °C … +85 °C |
| Process pressure | 0 bar … 6 bar, gauge pressure for UP56 Pure mini |
| Output signal | 1 x PNP + 4 mA … 20 mA / 0 V … 10 V
4 mA … 20 mA 4 mA … 20 mA, 2-wire |
